Trimwall

Trimwall is modular aluminium re-locatable partitioning system. Cost effective, attractive and available in both glazed and solid panels. Trimwall is a class leading performance system offering a wide range of technical achievements, including 60-minute fire rating and 41 dB Rw using 6mm glass.

With an overall panel thickness of just 90mm this solution offers a robust but contemporary demountable partition system. Trimwall is compatible with all other Neslo partition products.

The construction is designed to incorporate concealed fixings with no need for any wet trades. The partition cavity can accommodate electrical and mechanical services. Manifestations and graphics can be applied to the glazed modules to suit, and/or integral blinds can be fitted with either manual or electric controls.

For technical and further information contact info@neslopartitioning.co.uk or 03333 583 003

Ironmongery

Glass

Blinds

Doors

Installers

Design

dimensions

Dimensions

Single boarded 90mm
Double boarded 115mm

sound

Sound Tested

Solid single  – up to 45dB Rw
Solid double – up to 51dB Rw
Glazed single – 35dB Rw
Glazed double – 41dB Rw
(Tested using standard 12.5mm plasterboard)

build height

Build Height

Solid - Up to 8000mm
Glazed - Up to 4300mm

deflection

Deflection

+/- 15mm
+/- 25mm

fire rating

Fire Rating

Solid single – up to 60/60
Solid double – up to 120/120
Glazed – 60/0
(Tested to Fire Resistance Standard: BS 476:Part 22)

mechanical and electrical services

Services

M&E Services

design and environment

Design

All sections that make up our Trimwall system are designed and manufactured in the UK.
The system is fully relocatable and recyclable.
